Thickness Planer

A variety of thickness planer in our range whose cutting width from 10" to 12" and its cutting depth from 2.5 mm to 3.0 mm is rigid & robust portable power tools and its horse power is from 1600 W to 2000 W.

Name:

Thickness Planer

Item No. :

TP-2541

Specification:

Motor : 230V/50Hz             1600W
Speed : 8000/min
Feed Speed : 6m/min
Max.Cutting Width : 254mm
Plane Depth : 0～2.5mm
Thickness of suck : 6～130mm
Packing Size : 475X310X420mm
G.W/N.W. : 25/22.5kg
Loading Amount : 460pcs/20"container
                             925pcs/40"container
                             1056pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-2542

Specification:

Motor : 230V/50Hz             1600W
Speed : 8000min-1
Feed Speed : 6m/min
Max.Cutting Width : 254mm
Plane Depth : 0～2.5mm
Thickness of suck : 6～210mm
Packing Size : 475X310X500mm
G.W/N.W. : 26/23kg
Loading Amount : 368pcs/20"container
                             740pcs/40"container
                              880pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-2543

Specification:

Motor : 230V/50Hz            1800W
Speed : 8000min-1
Feed Speed : 6m/min
Max.Cutting Width : 254mm
Plane Depth : 0～3mm
Thickness of suck : 6～130mm
Packing Size : 475X310X420mm
G.W/N.W. : 25/22.5kg
Loading Amount : 460pcs/20"container
                              925pcs/40"container
                             1056pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-2545

Specification:

Motor : 230V/50Hz            1800W
Speed : 8000min-1
Feed Speed : 6m/min
Max.Cutting Width : 254mm
Plane Depth : 0～3mm
Thickness of suck : 6～210mm
Packing Size : 475X310X500mm
G.W/N.W. : 26/23kg
Loading Amount : 368pcs/20"container
                             740pcs/40"container
                             880pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-2546

Specification:

Motor : 230V/50Hz           2000W
Speed : 8000min^-1
Feed Speed : 6m/min
Max.Cutting Width : 254mm
Plane Depth : 0～3mm
Thickness of suck : 6～160mm
Packing Size : 570X360X455mm
G.W/N.W. : 32/29kg
Loading Amount : 332pcs/20"container
                             650pcs/40"container
                             752pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-3051

Specification:

Features:
with electric over loading protect fitting
GS/CE/EMC certificate met ROHS request.

Motor : 230V/50Hz 2000W
Speed : 8000min^-1
Feed Speed : 6m/min
Max.Cutting Width : 305mm
Plane Depth : 0～3mm

Thickness of suck : 6～160mm
Packing Size : 570X360X455mm
G.W/N.W. : 33/30kg
Loading Amount : 332pcs/20"container
650pcs/40"container
752pcs/40"high container

accessory:
1, crank                       1pcs
2, carbon brush           1pair
3, wrench(adjust blade screw)     1pcs
4, blade guage(adjust blade precision balance)  1pcs
5, inner hexagon spanner(adjust dust cover screw) 1pcs
6, belt   1pcs

Name:

Thickness Planer

Item No. :

TP-3052

Specification:

Motor : 230V/50Hz            2000W
Speed : 8000min^-1
Feed Speed : 6m/min
Max.Cutting Width : 305mm
Plane Depth : 0～3mm
Thickness of suck : 6～210mm
Packing Size : 570X360X505mm
G.W/N.W. : 34.2/31.0kg
Loading Amount : 288pcs/20"container
                             520pcs/40"container
                             650pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-3301

Specification:

Motor : 230V/50Hz            2000W
Speed: 8000min^-1
Feed Speed: 6m/min
Max.Cutting Width: 330mm
Plane Depth: 0～3mm
Thickness of suck: 6～160mm
Packing Size: 570X360X455mm
G.W/N.W. : 33/30kg
Loading Amount : 332pcs/20"container
                             650pcs/40"container
                             752pcs/40"high container

Name:

Thickness Planer

Item No. :

TP-3302

Specification:

Motor : 230V/50Hz            2000W
Speed : 8000min^-1
Feed Speed : 6m/min
Max.Cutting Width : 330mm
Plane Depth : 0～3mm
Thickness of suck : 6～210mm
Packing Size : 570X360X505mm
G.W/N.W. : 34.2/31.1kg
Loading Amount : 288pcs/20"container
                             520pcs/40"container
                             650pcs/40"high container

Name:

steel support

Item No. :

TP-02

Specification:

for supporting small planer to sure the machine body stablity
material: steel

Name:

machine stand support

Item No. :

TP-01

Specification:

Material: steel
color: black
height: 75cm
